1.1 橋架拼接點發生偏移

1.1 Bridge splice point offset

一般情況下，施工現場的環境的干擾性是影響橋架拼接點位置的關鍵因素之一，容易造成拼接點實現不了預期的規范要求，出彩易導致拼接點距離過大的情況出現。

In general, the interference of the construction site environment is one of the key factors affecting the position of bridge splice points, which can easily cause the splice points to fail to meet the expected regulatory requirements and easily lead to situations where the distance between splice points is too large.

1.2 錨固質量不佳

1.2 Poor anchoring quality

對于電纜橋架安裝中的土建工程而言，錨固工藝仍然具有較大的不足，即使完成錨固板安裝之后，還是與具體過程進展存在差距，難以真正保證橋架的穩定使用，在一定程度上制約著土建工程的錨固質量，嚴重影響著電纜橋架安裝的合理性。

For civil engineering in cable tray installation, the anchoring process still has significant shortcomings. Even after completing the installation of the anchoring plate, there is still a gap with the specific process progress, making it difficult to truly ensure the stable use of the cable tray. This to some extent restricts the anchoring quality of civil engineering and seriously affects the rationality of cable tray installation.

1.3 電纜參數的失真性

1.3 Distortion of cable parameters

通常在安裝人員對濟南電纜橋架安裝工藝進行檢查時，往往會在橋架的電纜路徑間出現托盤跳躍以及功能標記出錯、數據不全等情況，在一定程度上影響著橋架安裝的工程質量。

Usually, when the installation personnel inspect the installation process of Jinan cable tray, there are often tray jumps, incorrect functional markings, and incomplete data between the cable paths of the tray, which to some extent affects the engineering quality of tray installation.

2 解決核電站電纜橋架安裝質量問題的途徑

Ways to solve the quality problems of cable tray installation in nuclear power plants

2.1 更改拼接點設計

2.1 Change splicing point design

針對橋架拼接點不合理的現狀，相關的核電站電纜橋架安裝企業，要在實際的工程狀態的基礎上，對橋架安裝工作進行二次安排，科學對拼接點的位置進行合理規劃，并且進行體現，貫徹落實工程的監督職能，對具體拼接點的安裝位置進行有效管控，非常終實現合理的狀態。

In response to the current situation of unreasonable splicing points in cable trays, relevant nuclear power plant cable tray installation enterprises should make secondary arrangements for cable tray installation work based on the actual engineering status, scientifically plan and reflect the position of splicing points, implement the supervision function of the project, effectively control the installation position of specific splicing points, and ultimately achieve a reasonable state.

2.2 強化錨固控制

2.2 Strengthen anchoring control

若是遇到在核電站橋架電纜土建工程中發生錨固等問題，需要有效依據橋架的實際安裝操作規范，對方鋼錨固的位置進行移動，移動至偏離中心的位置上去，另一方面，還需要在相關的土建工程位置上焊接好方鋼，在配合好受力點的同時，對土建錨固的受力點進行調整，同時可以在連接螺栓的基礎上，對錨固板進行二次安裝，對之前的土建錨固設計進行再次的更改。

If there are anchoring and other issues encountered in the civil engineering of cable trays in nuclear power plants, it is necessary to effectively follow the actual installation operation specifications of the cable trays, move the position of the square steel anchoring to a position that is off center. On the other hand, it is also necessary to weld the square steel in the relevant civil engineering positions, adjust the force point of the civil anchoring while coordinating with the force point, and at the same time, install the anchoring plate again on the basis of connecting bolts, making changes to the previous civil anchoring design.

2.3 對電纜標識進行監督

2.3 Supervision of cable identification

在核電站電纜橋架安裝的工程單位的實際工作中，需要嚴格依據相關的工程監理規范，強調對細節的檢查，強化監理的力度。與此同時，在具體的施工階段內需要對電纜的標識進行嚴格的檢查，保證濟南電纜橋架屬性、功能等相。

In the actual work of the engineering unit for the installation of cable trays in nuclear power plants, it is necessary to strictly follow the relevant engineering supervision standards, emphasize the inspection of details, and strengthen the supervision efforts. At the same time, strict inspection of cable identification is required during the specific construction stage to ensure the attributes, functions, and other aspects of Jinan cable tray.
